Precision robotic actuator
ROBOTIC HARDWARE COMMISSION · VECTOR M1

Torque,
made legible.

A compact integrated joint combining structure, bearings, gearing, motor, sensing, braking, thermal management, and power-data routing in one serviceable module.

Actuator side profile
EXTERNAL ARCHITECTURE

One joint.
Multiple systems.

The housing separates mechanical load paths from electronics and service interfaces while preserving a compact rotational envelope.

OUTPUT
12-FASTENER FLANGE
HOUSING
GRAPHITE ALUMINUM CONCEPT
STATOR
COPPER WINDING RING
ENCODER
CERAMIC REAR CAP
CONNECTOR
POWER + DATA
REAL-TIME 7-AXIS ARM ASSEMBLY

Seven axes.
One arm.

Every joint stays registered to the base frame. Explode the whole arm, or isolate the structural, motor, sensing and thermal subsystems.

STRUCTURE / BEARINGS / GEARSET
STATOR / ROTOR / WINDINGS
ENCODER / CONTROL / DATA
THERMAL / HOUSING / SEALS
VECTOR M1Complete integrated actuator. Select a subsystem or use Director Play for a guided study.
INSTALLED LOAD CASE

From module
to moving system.

The actuator is shown in a robotic shoulder application. The load study visualizes joint demand and structural response without claiming verified torque or fatigue performance.

Actuator installed in robotic arm
ENGINEERING REVIEW

What must be
validated next.

The visual model defines interfaces and system relationships. Production readiness depends on measured hardware, calibrated control, and qualified engineering review.

OUTPUT FLANGE RUNOUTREQUIRES MEASUREMENT
BEARING PRELOADREQUIRES TEST
GEAR REDUCTION + BACKLASHREQUIRES SUPPLIER DATA
MOTOR CONSTANT + EFFICIENCYREQUIRES DYNO TEST
ENCODER ACCURACYREQUIRES CALIBRATION
THERMAL LIMITSREQUIRES LOAD PROFILE
BRAKE HOLDING CAPACITYREQUIRES SAFETY REVIEW
IP RATING + CONNECTORREQUIRES CERTIFICATION
ROBOTICS PRODUCT COMMISSION

Ready for a
client-specific build.

Product imagery, CAD-derived components, assembly logic, service instructions, load cases, specifications, and review workflows can all be connected through one structured hardware package.

Start a project

MODELVECTOR M1
ARCHITECTUREINTEGRATED JOINT CONCEPT
EXPLODED PARTS18 LIVE COMPONENTS
MOTORRADIAL FLUX CONCEPT
GEARSETSTRAIN-WAVE CONCEPT
OUTPUT / MASS / TORQUECONFIRM WITH ENGINEERING
SAFETY / CERTIFICATIONPROJECT REVIEW REQUIRED
VECTOR M1 is an illustrative concept for demonstration. Specifications, materials, performance, compliance, availability and pricing require verification.
